ATmega329/3290/649/6490
2552H–AVR–11/06
Table 96. Input Channel Selections
MUX4..0 Single Ended Input Positive Differential Input Negative Differential Input
00000 ADC0
N/A
00001 ADC1
00010 ADC2
00011 ADC3
00100 ADC4
00101 ADC5
00110 ADC6
00111 ADC7
01000
01001
01010
01011
01100
01101
01110
01111
10000 ADC0 ADC1
10001 ADC1 ADC1
10010 N/A ADC2 ADC1
10011 ADC3 ADC1
10100 ADC4 ADC1
10101 ADC5 ADC1
10110 ADC6 ADC1
10111 ADC7 ADC1
11000 ADC0 ADC2
11001 ADC1 ADC2
11010 ADC2 ADC2
11011 ADC3 ADC2
11100 ADC4 ADC2
11101 ADC5 ADC2
11110 1.1V (V
BG
) N/A
11111 0V (GND)
