265
ATmega329/3290/649/6490
2552H–AVR–11/06
99 PD5.Pull-up_Enable
98 PD6.Data
97 PD6.Control
96 PD6.Pull-up_Enable
95 PD7.Data
94 PD7.Control
93 PD7.Pull-up_Enable
92 PG0.Data Port G
91 PG0.Control
90 PG0.Pull-up_Enable
89 PG1.Data
88 PG1.Control
87 PG1.Pull-up_Enable
86 PC0.Data Port C
85 PC0.Control
84 PC0.Pull-up_Enable
83 PC1.Data
82 PC1.Control
81 PC1.Pull-up_Enable
80 PC2.Data
79 PC2.Control
78 PC2.Pull-up_Enable
77 PC3.Data
76 PC3.Control
75 PC3.Pull-up_Enable
74 PC4.Data
73 PC4.Control
72 PC4.Pull-up_Enable
71 PC5.Data
70 PC5.Control
69 PC5.Pull-up_Enable
68 PH0.Data Port H
67 PH0.Control
66 PH0.Pull-up_Enable
65 PH1.Data
64 PH1.Control
Table 114. ATmega3290/6490 Boundary-scan Order, 100-pin (Continued)
Bit Number Signal Name Module
