332
ATmega329/3290/649/6490
2552H–AVR–11/06
Figure 164. I/O Pin Source Current vs. Output Voltage, Ports A, C, D, E, F, G, H, J
(V
CC
= 1.8V)
Figure 165. I/O Pin Source Current vs. Output Voltage, Port B (V
CC
= 5V)
I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE, PORTS A, C, D, E, F, G, H, J
Vcc = 1.8V
0
1
2
3
4
5
6
7
8
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
V
OH
(V)
I OH
(m
A
)
85 °C
25 °C
-40 °C
I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE, PORT B
Vcc = 5V
0
10
20
30
40
50
60
70
80
0 1 2 3 4
V
OH
(V)
I OH
(m
A
)
85 °C
25 °C
-40 °C
