Idle Supply Current Figure 147. Idle Supply Current vs. Frequency (0.1 - 1.0 MHz)
Figure 148. Idle Supply Current vs. Frequency (1 - 16 MHz)
IDLE SUPPLY CURRENT vs. FREQUENCY
0.1 - 1.0 MHz
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.05
0.1
0.15
0.2
0.25
0.3
0.35
0.4
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I CC
(mA)
IDLE SUPPLY CURRENT vs. FREQUENCY
1 - 16 MHz
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
0
1
2
3
4
5
6
0 2 4 6 8 10 12 14 16
Frequency (MHz)
I CC
(mA)
1.8 V
