203
ATmega329/3290/649/6490
2552H–AVR–11/06
Analog to Digital
Converter
Features • 10-bit Resolution
• 0.5 LSB Integral Non-linearity
• ± 2 LSB Absolute Accuracy
• 13 µs - 260 µs Conversion Time (50 kHz to 1 MHz ADC clock)
• Up to 76.9 kSPS at Maximum Resolution (200 kHz ADC clock)
• Eight Multiplexed Single Ended Input Channels
• Optional Left Adjustment for ADC Result Readout
• 0 - V
CC
ADC Input Voltage Range
• Selectable 1.1V ADC Reference Voltage
• Free Running or Single Conversion Mode
• ADC Start Conversion by Auto Triggering on Interrupt Sources
• Interrupt on ADC Conversion Complete
• Sleep Mode Noise Canceler
The ATmega329/3290/649/6490 features a 10-bit successive approximation ADC. The
ADC is connected to an 8-channel Analog Multiplexer which allows eight single-ended
voltage inputs constructed from the pins of Port F. The single-ended voltage inputs refer
to 0V (GND).
The ADC contains a Sample and Hold circuit which ensures that the input voltage to the
ADC is held at a constant level during conversion. A block diagram of the ADC is shown
in Figure 84.
The ADC has a separate analog supply voltage pin, AVCC. AV
CC
must not differ more
than ± 0.3V from V
CC
. See the paragraph “ADC Noise Canceler” on page 209 on how to
connect this pin.
Internal reference voltages of nominally 1.1V or AVCC are provided On-chip. The volt-
age reference may be externally decoupled at the AREF pin by a capacitor for better
noise performance.
The PRADC, in “Power Reduction Register - PRR” on page 35 must be written to zero
to enable the ADC module.
