257
ATmega329/3290/649/6490
2552H–AVR–11/06
133 PB0.Data Port B
132 PB0.Control
131 PB0.Pull-up_Enable
130 PB1.Data
129 PB1.Control
128 PB1.Pull-up_Enable
127 PB2.Data
126 PB2.Control
125 PB2.Pull-up_Enable
124 PB3.Data
123 PB3.Control
122 PB3.Pull-up_Enable
121 PB4.Data
120 PB4.Control
119 PB4.Pull-up_Enable
118 PB5.Data
117 PB5.Control
116 PB5.Pull-up_Enable
115 PB6.Data
114 PB6.Control
113 PB6.Pull-up_Enable
112 PB7.Data
111 PB7.Control
110 PB7.Pull-up_Enable
109 PG3.Data Port G
108 PG3.Control
107 PG3.Pull-up_Enable
106 PG4.Data
105 PG4.Control
104 PG4.Pull-up_Enable
103 PG5 (Observe Only)
102 RSTT Reset Logic
(Observe-only)
101 RSTHV
Table 113. ATmega329/649 Boundary-scan Order, 64-pin (Continued)
Bit Number Signal Name Module
