349
ATmega329/3290/649/6490
2552H–AVR–11/06
Figure 198. Reset Supply Current vs. V
CC
(1 - 16 MHz, Excluding Current Through The
Reset Pull-up)
Figure 199. Reset Pulse Width vs. V
CC
RESET SUPPLY CURRENT vs. V
CC
1 - 16 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.5
1
1.5
2
2.5
3
0 2 4 6 8 10 12 14 16
Frequency (MHz)
I CC
(mA)
RESET PULSE WIDTH vs. V
CC
0
500
1000
1500
2000
2500
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Pu
ls
e
w
id
th
(
n
s
)
85 °C
25 °C
-40 °C
