Alternate Functions of Port C The Port C has an alternate function as SEG for the LCD Controller.
The alternate pin configuration is as follows:
• SEG – Port D, Bit 7:0
SEG, LCD front plane 5/5, 6/6, 11/7-16/12.
Table 34 and Table 35 relate the alternate functions of Port C to the overriding signals
shown in Figure 27 on page 65.
Table 32. Overriding Signals for Alternate Functions in PB3:PB0
Signal
Name PB3/MISO/
PCINT11 PB2/MOSI/
PCINT10 PB1/SCK/
PCINT9 PB0/SS/
PCINT8
PUOE SPE • MSTR SPE • MSTR SPE • MSTR SPE • MSTR
PUOV PORTB3 • PUD PORTB2 • PUD PORTB1 • PUD PORTB0 • PUD
DDOE SPE • MSTR SPE • MSTR SPE • MSTR SPE • MSTR
DDOV 0 0 0 0
PVOE SPE • MSTR SPE • MSTR SPE • MSTR 0
PVOV SPI SLAVE
OUTPUT SPI MSTR
OUTPUT SCK OUTPUT 0
PTOE – – – –
DIEOE PCINT11 •
PCIE1 PCINT10 •
PCIE1 PCINT9 • PCIE1 PCINT8 • PCIE1
DIEOV 1 1 1 1
DI PCINT11 INPUT
SPI MSTR
INPUT
PCINT10 INPUT
SPI SLAVE
INPUT
PCINT9 INPUT
SCK INPUT
PCINT8 INPUT
SPI SS
AIO – – – –
Table 33. Port C Pins Alternate Functions (SEG refers to 100-pin/64-pin pinout)
Port Pin Alternate Function
PC7 SEG (LCD Front Plane 5/5)
PC6 SEG (LCD Front Plane 6/6)
PC5 SEG (LCD Front Plane 11/7)
PC4 SEG (LCD Front Plane 12/8)
PC3 SEG (LCD Front Plane 13/9)
PC2 SEG (LCD Front Plane14/10)
PC1 SEG (LCD Front Plane 15/11)
PC0 SEG (LCD Front Plane 16/12)
