263
ATmega329/3290/649/6490
2552H–AVR–11/06
171 PB0.Control
170 PB0.Pull-up_Enable
169 PB1.Data
168 PB1.Control
167 PB1.Pull-up_Enable
166 PB2.Data
165 PB2.Control
164 PB2.Pull-up_Enable
163 PB3.Data
162 PB3.Control
161 PB3.Pull-up_Enable
160 PB4.Data
159 PB4.Control
158 PB4.Pull-up_Enable
157 PB5.Data
156 PB5.Control
155 PB5.Pull-up_Enable
154 PB6.Data
153 PB6.Control
152 PB6.Pull-up_Enable
151 PB7.Data
150 PB7.Control
149 PB7.Pull-up_Enable
148 PG3.Data Port G
147 PG3.Control
146 PG3.Pull-up_Enable
145 PG4.Data
144 PG4.Control
143 PG4.Pull-up_Enable
142 PG5 (Observe Only)
141 RSTT Reset Logic
(Observe-only)
140 RSTHV
139 EXTCLKEN Enable signals for main Clock/Oscillators
138 OSCON
137 RCOSCEN
136 OSC32EN
Table 114. ATmega3290/6490 Boundary-scan Order, 100-pin (Continued)
Bit Number Signal Name Module
