334
ATmega329/3290/649/6490
2552H–AVR–11/06
Figure 168. I/O Pin Sink Current vs. Output Voltage, Ports A, C, D, E, F, G, H, J
(V
CC
= 5V)
Figure 169. I/O Pin Sink Current vs. Output Voltage, Ports A, C, D, E, F, G, H, J
(V
CC
= 2.7V)
I/O PIN SINK CURRENT vs. OUTPUT VOLTAGE, PORTS A, C, D, E, F, G, H, J
Vcc = 5V
0
5
10
15
20
25
30
35
40
45
50
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
V
OL
(V)
I OL
(m
A
)
85 °C
25 °C
-40 °C
I/O PIN SINK CURRENT vs. OUTPUT VOLTAGE, PORTS A, C, D, E, F, G, H, J
Vcc = 2.7V
0
2
4
6
8
10
12
14
16
18
20
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
V
OL
(V)
I OL
(m
A
)
85 °C
25 °C
-40 °C
