330
ATmega329/3290/649/6490
2552H–AVR–11/06
Figure 160. Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 2.7V)
Figure 161. Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 1.8V)
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
Vcc = 2.7V
0
10
20
30
40
50
60
70
0 0.5 1 1.5 2 2.5 3
V
RESET
(V)
I R
ESET
(u
A
)
-40 °C
25 °C
85 °C
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
Vcc = 1.8V
0
5
10
15
20
25
30
35
40
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
V
RESET
(V)
I R
ESET
(u
A
)
-40 °C
25 °C
85 °C
