267
ATmega329/3290/649/6490
2552H–AVR–11/06
Note: 1. PRIVATE_SIGNAL1 should always be scanned in as zero.
Boundary-scan
Description Language
Files Boundary-scan Description Language (BSDL) files describe Boundary-scan capable
devices in a standard format used by automated test-generation software. The order
and function of bits in the Boundary-scan Data Register are included in this description.
A BSDL file for ATmega329/3290/649/6490 is available.
27 PA1.Pull-up_Enable
26 PA0.Data
25 PA0.Control
24 PA0.Pull-up_Enable
23 PH4.Data Port H
22 PH4.Control
21 PH4.Pull-up_Enable
20 PH5.Data
19 PH5.Control
18 PH5.Pull-up_Enable
17 PH6.Data
16 PH6.Control
15 PH6.Pull-up_Enable
14 PH7.Data
13 PH7.Control
12 PH7.Pull-up_Enable
11 PF3.Data Port F
10 PF3.Control
9 PF3.Pull-up_Enable
8 PF2.Data
7 PF2.Control
6 PF2.Pull-up_Enable
5 PF1.Data
4 PF1.Control
3 PF1.Pull-up_Enable
2 PF0.Data
1 PF0.Control
0 PF0.Pull-up_Enable
Table 114. ATmega3290/6490 Boundary-scan Order, 100-pin (Continued)
Bit Number Signal Name Module
