W90N740
- 90 -
MAC MII Management Data Register (MIID_0, MIID_1)
W90N740 provides MII management function to let user access the registers of the
external physical layer device. Setting options in MII management registers does not
affect the MAC controller operation.
Register Address R/W Description Reset Value
MIID_0 0xFFF0.3090 R/W MII Management Data Register 0x0000.0000
MIID_1 0xFFF0.3890 R/W MII Management Data Register 0x0000.0000
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8
MIIData
7 6 5 4 3 2 1 0
MIIData
MIIData [15:0]: MII station management data
This register contains a 16-bit data value for the MII station management function.
