W90N740
- 214 -
AIC Registers Map
REGISTER ADDRESS
R/W
DESCRIPTION
RESET
VALUE
AIC_SCR1 0xFFF8.2004
R/W
Source Control Register 1
0x0000.0047
AIC_SCR2 0xFFF8.2008
R/W
Source Control Register 2
0x0000.0047
AIC_SCR3 0xFFF8.200C
R/W
Source Control Register 3
0x0000.0047
AIC_SCR4 0xFFF8.2010
R/W
Source Control Register 4
0x0000.0047
AIC_SCR5 0xFFF8.2014
R/W
Source Control Register 5
0x0000.0047
AIC_SCR6 0xFFF8.2018
R/W
Source Control Register 6
0x0000.0047
AIC_SCR7 0xFFF8.201C
R/W
Source Control Register 7
0x0000.0047
AIC_SCR8 0xFFF8.2020
R/W
Source Control Register 8
0x0000.0047
AIC_SCR9 0xFFF8.2024
R/W
Source Control Register 9
0x0000.0047
AIC_SCR10 0xFFF8.2028
R/W
Source Control Register 10
0x0000.0047
AIC_SCR11 0xFFF8.202C
R/W
Source Control Register 11
0x0000.0047
AIC_SCR12 0xFFF8.2030
R/W
Source Control Register 12
0x0000.0047
AIC_SCR13 0xFFF8.2034
R/W
Source Control Register 13
0x0000.0047
AIC_SCR14 0xFFF8.2038
R/W
Source Control Register 14
0x0000.0047
AIC_SCR15 0xFFF8.203C
R/W
Source Control Register 15
0x0000.0047
AIC_SCR16
0xFFF8.2040
R/W
Source Control Register 16
0x0000.0000
AIC_SCR17
0xFFF8.2044
R/W
Source Control Register 17
0x0000.0000
AIC_SCR18
0xFFF8.2048
R/W
Source Control Register 18
0x0000.0000
AIC_IRSR 0xFFF8.2100
R
Interrupt Raw Status Register
0x0000.0000
AIC_IASR 0xFFF8.2104
R
Interrupt
Active Status Register
0x0000.0000
AIC_ISR 0xFFF8.2108
R
Interrupt Status Register
0x0000.0000
AIC_IPER 0xFFF8.210C
R
Interrupt
Priority Encoding Register
0x0000.0000
AIC_ISNR
0xFFF8.2110
R
Interrupt Source Number Register
0x0000.0000
AIC_IMR 0xFFF8.2114
R
Interrupt Mask Register
0x0000.0000
AIC_OISR
0xFFF8.2118
R
Output Interrupt Status Register
0x0000.0000
AIC_MECR
0xFFF8.2120
W
Mask Enable Command Register
Undefined
AIC_MDCR
0xFFF8.2124
W
Mask Disable Command Register
Undefined
AIC_SSCR 0xFFF8.2128
W
Source
Set Command Register
Undefined
AIC_SCCR 0xFFF8.212C
W
Source
Clear Command Register
Undefined
AIC_EOSCR
0xFFF8.2130
W
End of Service Command Register
Undefined
