W90N740
Publication Release Date: November 26, 2004
- 181 - Revision A4
AIC Interrupt Mask Register (AIC_IMR)
Register Address R/W Description Reset Value
AIC_IMR 0xFFF8.2114 R Interrupt Mask Register 0x0000.0000
31 30 29 28 27 26 25 24
RESERVED
23 22 21 20 19 18 17 16
RESERVED IM18 IM17 IM16
15 14 13 12 11 10 9 8
IM15 IM14 IM13 IM12 IM11 IM10 IM9 IM8
7 6 5 4 3 2 1 0
IM7 IM6 IM5 IM4 IM3 IM2 IM1 RESERVED
IM x: Interrupt Mask
This bit determines whether the corresponding interrupt channel is enabled or disabled. Every
interrupt channel can be active no matter whether it is enabled or disabled. If an interrupt channel is
enabled, it does not definitely mean it is active. Every interrupt channel can be authorized by the AIC
only when it is both active and enabled.
0 = Corresponding interrupt channel is disabled
1 = Corresponding interrupt channel is enabled
