W90N740
Publication Release Date: November 26, 2004
- 97 -
Revision A4
Transmit Start Demand Register (TSDR_0, TSDR_1)
Register Address
R/W
Description
Reset
Value
TSDR_0 0xFFF0.30A8 W Transmit
Start Demand Register
Undefined
TSDR_1 0xFFF0.38A8 W Transmit
Start Demand Register
Undefined
31
30
29
28
27
26
25
24
TSDR
23
22
21
20
19
18
17
16
TSDR
15
14
13
12
11
10
9
8
TSDR
7
6
5
4
3
2
1
0
TSDR
TSDR [31:0]: Transmit Start Demand Register
Default value: Undefined
While the transmit descriptor is unavailable, the Tx state machine will enter Halt state. The user has to
issue a write command with any data to Transmit Start Demand register to restart the Tx operation.
Only while Tx state machine stay at Halt state, the write command to Transmit Start Demand register
can affect the Tx operation.
