W90N740
Publication Release Date: November 26, 2004
- 67 - Revision A4
To flush the entire I-Cache/D-Cache, also flushes any locked-down code. If the I-Cache/D-Cache
contains locked down code, the programmer must flush lines individually.
DCAH [1] ：D-Cache selected
When set to “1”, the command set is executed with D-Cache.
ICAH [0] ：I-Cache selected
When set to “1”, the command set is executed with I-Cache.
Notes：When using the FLHA or ULKA command, you can set both ICAH and DCAH bits to execute
entire I-Cache and D-Cache flushing or unlocking. But, FLHS and ULKS commands can only be
executed with a cache line specified by CAHADR register in I-Cache or D-Cache at a time. If you set
both ICAH and DCAH bits, and set FLHS or ULKS command bit, it will be treated as an invalid
command and no operation is done and the command terminates with no exception.
The Drain Write Buffer operation is only for D-Cache. To perform this operation, you must set DRWB
and DCAH bits. If the ICAH bit is set when using DRWB command, it will be an invalid command and no
operation is done and the command terminates with no exception.
Cache Address Register (CAHADR)
W90N740 Cache Controller supports one address register. This address register is used with the
command set in the control register (CAHCON) by specifying instruction/data address.
Register Address R/W Description Reset Value
CAHADR 0xFFF0.2008 R/W Cache address register 0x0000.0000
31 30 29 28 27 26 25 24
WAY ADDR
23 22 21 20 19 18 17 16
ADDR
15 14 13 12 11 10 9 8
ADDR
7 6 5 4 3 2 1 0
ADDR
WAY [31] ：Way selection
0 = Way0 is selected
1 = Way1 is selected
ADDR [30:0] ：The absolute address of instruction or data
