7.6.2 NATA Registers Map
This set of registers is used to convey status/control information to/from the NAT engine. These
registers are used for loading commands generated by user, indicating network translation status, and
providing interrupt control.
The registers used by W90N740 NATA controller are divided into two groups:
„ NATA Control and Status Registers
„ Address Look Up and Replacement Entry Registers
REGISTER OFFSET R/W DESCRIPTION RESET VALUE
NATA Control and Status Registers
NATCMD 0xFFF0.6000 R/W NAT Command Register 0x0000.0000
NATCCLR0 0xFFF0.6010 W NAT Counter 0 Clear Register 0x0000.0000
NATCCLR1 0xFFF0.6014 W NAT Counter 1 Clear Register 0x0000.0000
NATCCLR2 0xFFF0.6018 W NAT Counter 2 Clear Register 0x0000.0000
NATCCLR3 0xFFF0.601C W NAT Counter 3 Clear Register 0x0000.0000
NATCFG0 0xFFF0.6100 R/W NAT Entry 0 Configuration Register 0x0000.0000
NATCFG1 0xFFF0.6104 R/W NAT Entry 1 Configuration Register 0x0000.0000
.
.
.
.
.
. .
.
.
.
.
. .
.
.
.
.
. .
.
.
.
.
. .
.
.
.
.
.
NATCFG63 0xFFF0.61FC R/W NAT Entry 63 Configuration Register 0x0000.0000
EXMACM 0xFFF0.6200 R/W
External MAC Address Most Significant Word
Register
0x0000.0000
EXMACL 0xFFF0.6204 R/W
External MAC Address Least Significant Word
Register
0x0000.0000
INMACM 0xFFF0.6208 R/W
Internal MAC Address Most Significant Word
Register
0x0000.0000
INMACL 0xFFF0.620C R/W
Internal MAC Address Least Significant Word
Register
0x0000.0000
