W90N740
- 204 -
EMC 0 Control registers Map
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
CAM REGISTERS
CAMCMR_0 0xFFF0.3000 R/W CAM
Command Register
0x0000.0000
CAMEN_0 0xFFF0.3004
R/W
CAM enable register
0x0000.0000
CAM1M_0
0xFFF0.3008
R/W
CAM1 Most Significant Word Register
0x0000.0000
CAM1L_0
0xFFF0.300C
R/W
CAM1 Least Significant Word Register
0x0000.0000
CAM2M_0
0xFFF0.3010
R/W
CAM2 Most Significant Word Register
0x0000.0000
CAM2L_0
0xFFF0.3014
R/W
CAM2 Least Significant Word Register
0x0000.0000
CAM3M_0
0xFFF0.3018
R/W
CAM3 Most Significant Word Register
0x0000.0000
CAM3L_0
0xFFF0.301C
R/W
CAM3 Least Significant Word Register
0x0000.0000
CAM4M_0
0xFFF0.3020
R/W
CAM4 Most Significant Word Register
0x0000.0000
CAM4L_0
0xFFF0.3024
R/W
CAM4 Least Significant Word Register
0x0000.0000
CAM5M_0
0xFFF0.3028
R/W
CAM5 Most Significant Word Register
0x0000.0000
CAM5L_0
0xFFF0.302C
R/W
CAM5 Least Significant Word Register
0x0000.0000
CAM6M_0
0xFFF0.3030
R/W
CAM6 Most Significant Word Register
0x0000.0000
CAM6L_0
0xFFF0.3034
R/W
CAM6 Least Significant Word Register
0x0000.0000
CAM7M_0
0xFFF0.3038
R/W
CAM7 Most Significant Word Register
0x0000.0000
CAM7L_0
0xFFF0.303C
R/W
CAM7 Least Significant Word Register
0x0000.0000
CAM8M_0
0xFFF0.3040
R/W
CAM8 Most Significant Word Register
0x0000.0000
CAM8L_0
0xFFF0.3044
R/W
CAM8 Least Significant Word Register
0x0000.0000
CAM9M_0
0xFFF0.3048
R/W
CAM9 Most Significant Word Register
0x0000.0000
CAM9L_0
0xFFF0.304C
R/W
CAM9 Least Significant Word Register
0x0000.0000
CAM10M_0
0xFFF0.3050
R/W
CAM10 Most Significant Word Register
0x0000.0000
CAM10L_0
0xFFF0.3054
R/W
CAM10 Least Significant Word Register
0x0000.0000
CAM11M_0
0xFFF0.3058
R/W
CAM11 Most Significant Word Register
0x0000.0000
CAM11L_0
0xFFF0.305C
R/W
CAM11 Least Significant Word Register
0x0000.0000
CAM12M_0
0xFFF0.3060
R/W
CAM12 Most Significant Word Register
0x0000.0000
CAM12L_0
0xFFF0.3064
R/W
CAM12 Least Significant Word Register
0x0000.0000
CAM13M_0
0xFFF0.3068
R/W
CAM13 Most Significant Word Register
0x0000.0000
CAM13L_0
0xFFF0.306C
R/W
CAM13 Least Significant Word Register
0x0000.0000
CAM14M_0
0xFFF0.3070
R/W
CAM14 Most Significant Word Register
0x0000.0000
CAM14L_0
0xFFF0.3074
R/W
CAM14 Least Significant Word Register
0x0000.0000
