W90N740
Publication Release Date: November 26, 2004
- 29 - Revision A4
7.2.7 System Manager Control Registers Map
Register Address R/W Description Reset Value
PDID 0xFFF0.0000 R Product Identifier Register 0xX090.0740
ARBCON 0xFFF0.0004 R/W Arbitration Control Register 0x0000.0000
PLLCON 0xFFF0.0008 R/W PLL Control Register 0x0000.2F01
CLKSEL 0xFFF0.000C R/W Clock Select Register 0x0000.3FX8
Product Identifier Register （PDID）
This register is for read only and enables software to recognize certain characteristics of the chip ID and
the version number.
Register Address R/W Description Reset Value
PDID 0xFFF0.0000 R Product Identifier Register 0xX090.0740
31 30 29 28 27 26 25 24
PACKAGE 1
23 22 21 20 19 18 17 16
CHPID
15 14 13 12 11 10 9 8
CHPID
7 6 5 4 3 2 1 0
CHPID
PACKAGE [31:30] Package Type
Package [31:30] Bus Width
1 1 176-pin Package
CHPID [23:0]: Chip identifier
The Chip identifier of W90N740 is 0x90.0740
