W90N740
Publication Release Date: November 26, 2004
- 205 - Revision A4
EMC 0 Control registers Map, continued
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
CAM REGISTERS
CAM15M_0
0xFFF0.3078 R/W CAM15 Most Significant Word Register 0x0000.0000
CAM15L_0 0xFFF0.307C R/W CAM15 Least Significant Word Register 0x0000.0000
CAM16M_0 0xFFF0.3080 R/W CAM16 Most Significant Word Register 0x0000.0000
CAM16L_0 0xFFF0.3084 R/W CAM16 Least Significant Word Register 0x0000.0000
MAC REGISTERS
MIEN_0 0xFFF0.3088
R/W MAC Interrupt Enable Register 0x0000.0000
MCMDR_0 0xFFF0.308C R/W MAC Command Register 0x0000.0000
MIID_0 0xFFF0.3090 R/W MII Management Data Register 0x0000.0000
MIIDA_0 0xFFF0.3094 R/W
MII Management Data Control and Address
Register
0x0090.0000
MPCNT_0 0xFFF0.3098 R/W Missed Packet counter register 0x0000.7FFF
DMA REGISTERS
TXDLSA_0 0xFFF0.309C R/W
Transmit Descriptor Link List Start Address
register
0xFFFF.FFFC
RXDLSA_0 0xFFF0.30A0 R/W
Receive Descriptor Link List Start Address
register
0xFFFF.FFFC
DMARFC_0 0xFFF0.30A4 R/W DMA Receive Frame Control Register 0x0000.0800
TSDR_0 0xFFF0.30A8 W Transmit Start Demand Register Undefined
RSDR_0 0xFFF0.30AC W Receive Start Demand Register Undefined
FIFOTHD_0 0xFFF0.30B0 R/W FIFO Threshold Adjustment Register 0x0000.0101
