W90N740
- 182 -
AIC Output Interrupt Status Register (AIC_OISR)
Register Address R/W Description Reset Value
AIC_OISR 0xFFF8.2118 R Output Interrupt Status Register 0x0000.0000
31 30 29 28 27 26 25 24
RESERVED
23 22 21 20 19 18 17 16
RESERVED
15 14 13 12 11 10 9 8
RESERVED
7 6 5 4 3 2 1 0
RESERVED IRQ FIQ
The AIC classifies the interrupt into FIQ and IRQ. This register indicates whether the asserted interrupt is
FIQ or IRQ. If both IRQ and FIQ are equal to 0, it means there is no interrupt occurred.
IRQ [1]: Interrupt Request
0 = nIRQ line is inactive.
1 = nIRQ line is active.
FIQ [0]: Fast Interrupt Request
0 = nFIQ line is inactive.
1 = nFIQ line is active
