W90N740
- 168 -
TIC [23:0]: Timer Initial Count
This is a 24-bit value representing the initial count. Timer will reload this value whenever the counter is
decremented to zero.
Timer Data Register 0 (TDR0)
Timer Data Register 1 (TDR1)
Register Address R/W/C Description Reset Value
TDR0 0xFFF8.1010 R Timer Data Register 0 0x0000.00FF
TDR1 0xFFF8.1014 R Timer Data Register 1 0x0000.00FF
31 30 29 28 27 26 25 24
RESERVED
23 22 21 20 19 18 17 16
TDR [23:16]
15 14 13 12 11 10 9 8
TDR [15:8]
7 6 5 4 3 2 1 0
TDR [7:0]
TDR [23:0]: Timer Data Register
The current count is registered in this 24-bit value.
