W90N740
Publication Release Date: November 26, 2004
- 75 - Revision A4
EMC 0 Control registers, continued
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
CAM REGISTERS
CAM9L_0 0xFFF0.3054 R/W CAM9 Least Significant Word Register 0x0000.0000
CAM10M_0 0xFFF0.3058 R/W CAM10 Most Significant Word Register 0x0000.0000
CAM10L_0 0xFFF0.305C R/W CAM10 Least Significant Word Register 0x0000.0000
CAM11M_0 0xFFF0.3060 R/W CAM11 Most Significant Word Register 0x0000.0000
CAM11L_0 0xFFF0.3064 R/W CAM11 Least Significant Word Register 0x0000.0000
CAM12M_0 0xFFF0.3068 R/W CAM12 Most Significant Word Register 0x0000.0000
CAM12L_0 0xFFF0.306C R/W CAM12 Least Significant Word Register 0x0000.0000
CAM13M_0 0xFFF0.3070 R/W CAM13 Most Significant Word Register 0x0000.0000
CAM13L_0 0xFFF0.3074 R/W CAM13 Least Significant Word Register 0x0000.0000
CAM14M_0 0xFFF0.3078 R/W CAM14 Most Significant Word Register 0x0000.0000
CAM14L_0 0xFFF0.307C R/W CAM14 Least Significant Word Register 0x0000.0000
CAM15M_0 0xFFF0.3080 R/W CAM15 Most Significant Word Register 0x0000.0000
CAM15L_0 0xFFF0.3084 R/W CAM15 Least Significant Word Register 0x0000.0000
MAC REGISTERS
MIEN_0 0xFFF0.3088 R/W MAC Interrupt Enable Register 0x0000.0000
MCMDR_0 0xFFF0.308C R/W MAC Command Register 0x0000.0000
MIID_0 0xFFF0.3090 R/W MII Management Data Register 0x0000.0000
MIIDA_0 0xFFF0.3094 R/W MII Management Data Control and Address Register 0x0090.0000
MPCNT_0 0xFFF0.3098 R/W Missed Packet counter register 0x0000.7FFF
DMA REGISTERS
TXDLSA_0 0xFFF0.309C R/W Transmit Descriptor Link List Start Address register 0xFFFF.FFFC
RXDLSA_0 0xFFF0.30A0 R/W Receive Descriptor Link List Start Address register 0xFFFF.FFFC
DMARFC_0 0xFFF0.30A4 R/W DMA Receive Frame Control Register 0x0000.0800
TSDR_0 0xFFF0.30A8 W Transmit Start Demand Register Undefined
RSDR_0 0xFFF0.30AC W Receive Start Demand Register Undefined
FIFOTHD_0 0xFFF0.30B0 R/W FIFO Threshold Adjustment Register 0x0000.0101
