W90N740
- 22 -
Table 7.2.7 and Table 7.2.8
Using big-endian and byte access, Program/Data path between register and external memory.
BA = Address whose LSB is 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, F
BAL = Address whose LSB is 0, 2, 4, 6, 8, A, C, E BAU = Address whose LSB is 1, 3, 5, 7, 9, B, D,
F
BA0 = Address whose LSB is 0, 4, 8, C BA1 = Address whose LSB is 1, 5, 9, D
BA2 = Address whose LSB is 2, 6, A, E BA3 = Address whose LSB is 3, 7, B, F
Table7.2.7 Byte access write operation with Big Endian
Access Operation Write Operation (CPU Register Î External Memory)
XD Width Word Half Word Byte
Bit Number
CPU Reg Data
31 0
ABCD
31 0
ABCD
31 0
ABCD
SA BA0 BA1 BA2 BA3 BAL BAU BA
Bit Number
SD
31 0
D D D D
31 0
D D D D
31 0
D D D D
31 0
D D D D
31 0
D D D D
31 0
D D D D
31 0
D D D D
Bit Number
ED
31 24
D
23 16
D
15 8
D
7 0
D
15 8
D
7 0
D
7 0
D
XA BA0 BA0 BA0 BA0 BAL BAL BA
nWBE [3-0] /
SDQM [3-0]
AUUU UAUU UUAU UUUA XXAU XXUA XXXA
Bit Number
XD
31 0
D X X X
31 0
X D X X
31 0
X X D X
31 0
X X X D
15 0
D X
15 0
X D
7 0
D
Bit Number
Ext. Mem Data
31 24
D
23 16
D
15 8
D
7 0
D
15 8
D
7 0
D
7 0
D
Timing Sequence
