W90N740
Publication Release Date: November 26, 2004
- 135 - Revision A4
Channel 0/1 Current Destination Register (GDMA_CDST0, GDMA_CDST1)
Register Address R/W Description Reset Value
GDMA_CDST0 0xFFF0.4014 R Channel 0 Current Destination Address Register 0x0000.0000
GDMA_CDST1 0xFFF0.4034 R Channel 1 Current Destination Address Register 0x0000.0000
31 30 29 28 27 26 25 24
CURRENT_DST_ADDR [31:24]
23 22 21 20 19 18 17 16
CURRENT_DST_ADDR [23:16]
15 14 13 12 11 10 9 8
CURRENT_DST_ADDR [15:8]
7 6 5 4 3 2 1 0
CURRENT_DST_ADDR [7:0]
CURRENT_DST_ADDR [31:0]: 32-bit Current Destination Address
The CURRENT_DST_ADDR indicates the destination address where the GDMA transfer is just
occurring. During a block transfer, the GDMA determines the successive destination addresses by
adding to or subtracting from the destination base address. Depending on the settings you make to the
control register, the current destination address will remain the same or will be incremented or
decremented.
Channel 0/1 Current Transfer Count Register (GDMA_CTCNT0, GDMA_CTCNT1)
The Current transfer count register indicates the number of transfer being performed.
Register Address R/W Description Reset Value
GDMA_CTCNT0 0xFFF0.4018 R Channel 0 Current Transfer Count Register 0x0000.0000
GDMA_CTCNT1 0xFFF0.4038 R Channel 1 Current Transfer Count Register 0x0000.0000
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
CURENT_TFR_CNT [23:16]
15 14 13 12 11 10 9 8
CURRENT_TFR_CNT [15:8]
7 6 5 4 3 2 1 0
CURRENT_TFR_CNT [7:0]
CURRENT_TFR_CNT [23:0]: Current Transfer Count
