W90N740
Publication Release Date: November 26, 2004
- 117 - Revision A4
REGISTER OFFSET R/W DESCRIPTION RESET VALUE
Address Lookup and Replacement Registers
MASAD0 0xFFF0.6800 R/W NAT Masquerading IP Address Entry 0 0x0000.0000
MASPN0 0xFFF0.6804 R/W NAT Masquerading Port Number Entry 0 0x0000.0000
LSAD0 0xFFF0.6808 R/W Local Station IP Address Entry 0 0x0000.0000
LSPN0 0xFFF0.680C R/W Local Station Port Number Entry 0 0x0000.0000
LSMAC0M 0xFFF0.6810 R/W
Local Station MAC Address Most Significant Word
Register for Entry 0
0x0000.0000
LSMAC0L 0xFFF0.6814 R/W
Local Station MAC Address Least Significant Word
Register for Entry 0
0x0000.0000
RSMAC0M 0xFFF0.6818 R/W
Remote Station MAC Address Most Significant
Word Register for Entry 0
0x0000.0000
RSMAC0L 0xFFF0.681C R/W
Remote Station MAC Address Least Significant
Word Register for Entry 0
0x0000.0000
MASAD1 0xFFF0.6820 R/W NAT Masquerading IP Address Entry 1 0x0000.0000
MASPN1 0xFFF0.6824 R/W NAT Masquerading Port Number Entry 1 0x0000.0000
LSAD1 0xFFF0.6828 R/W Local Station IP Address Entry 1 0x0000.0000
LSPN1 0xFFF0.682C R/W Local Station Port Number Entry 1 0x0000.0000
LSMAC1M 0xFFF0.6830 R/W
Local Station MAC Address Most Significant Word
Register for Entry 1
0x0000.0000
LSMAC1L 0xFFF0.6834 R/W
Local Station MAC Address Least Significant Word
Register for Entry 1
0x0000.0000
RSMAC1M 0xFFF0.6838 R/W
Remote Station MAC Address Most Significant
Word Register for Entry 1
0x0000.0000
RSMAC1L 0xFFF0.683C R/W
Remote Station MAC Address Least Significant
Word Register for Entry 1
0x0000.0000
.
.
.
. .
.
.
. .
.
.
. .
.
.
. .
.
.
.
MASAD63 0xFFF0.6FE0 R/W NAT Masquerading IP Address Entry 63 0x0000.0000
MASPN63 0xFFF0.6FE4 R/W NAT Masquerading Port Number Entry 63 0x0000.0000
LSAD63 0xFFF0.6FE8 R/W Local Station IP Address Entry 63 0x0000.0000
LSPN63 0xFFF0.6FEC R/W Local Station Port Number Entry 63 0x0000.0000
LSMAC63M 0xFFF0.6FF0 R/W
Local Station MAC Address Most Significant Word
Register for Entry 63
0x0000.0000
LSMAC63L 0xFFF0.6FF4 R/W
Local Station MAC Address Least Significant Word
Register for Entry 63
0x0000.0000
RSMAC63M 0xFFF0.6FF8 R/W
Remote Station MAC Address Most Significant
Word Register for Entry 63
0x0000.0000
RSMAC63L 0xFFF0.6FFC R/W
Remote Station MAC Address Least Significant
Word Register for Entry 63
0x0000.0000
