W90N740
- 76 -
EMC 0 Status Registers
Register Address R/W Description Reset Value
MAC REGISTERS
MISTA_0 0xFFF0.30B4 R/W MAC Interrupt Status Register 0x0000.0000
MGSTA_0 0xFFF0.30B8 R/W MAC General Status Register 0x0000.0000
MRPC_0 0xFFF0.30BC R MAC Receive Pause count register 0x0000.0000
MRPCC_0 0xFFF0.30C0 R MAC Receive Pause Current Count Register 0x0000.0000
MREPC_0 0xFFF0.30C4 R MAC Remote pause count register 0x0000.0000
DMA REGISTERS
DMARFS_0 0xFFF0.30C8 R/W DMA Receive Frame Status Register 0x0000.0000
CTXDSA_0 0xFFF0.30CC R
Current Transmit Descriptor Start Address
Register
0x0000.0000
CTXBSA_0 0xFFF0.30D0 R Current Transmit Buffer Start Address Register 0x0000.0000
CRXDSA_0 0xFFF0.30D4 R
Current Receive Descriptor Start Address
Register
0x0000.0000
CRXBSA_0 0xFFF0.30D8 R Current Receive Buffer Start Address Register 0x0000.0000
EMC 1 Control Registers
Register Address R/W Description Reset Value
CAM REGISTERS
CAMCMR_1 0xFFF0.3800 R/W CAM Command Register 0x0000.0000
CAMEN_1 0xFFF0.3804 R/W CAM enable register 0x0000.0000
CAM0M_1 0xFFF0.3808 R/W CAM0 Most Significant Word Register 0x0000.0000
CAM0L_1 0xFFF0.380C R/W CAM0 Least Significant Word Register 0x0000.0000
CAM1M_1 0xFFF0.3810 R/W CAM1 Most Significant Word Register 0x0000.0000
CAM1L_1 0xFFF0.3814 R/W CAM1 Least Significant Word Register 0x0000.0000
CAM2M_1 0xFFF0.3818 R/W CAM2 Most Significant Word Register 0x0000.0000
CAM2L_1 0xFFF0.381C R/W CAM2 Least Significant Word Register 0x0000.0000
CAM3M_1 0xFFF0.3820 R/W CAM3 Most Significant Word Register 0x0000.0000
CAM3L_1 0xFFF0.3824 R/W CAM3 Least Significant Word Register 0x0000.0000
CAM4M_1 0xFFF0.3828 R/W CAM4 Most Significant Word Register 0x0000.0000
CAM4L_1 0xFFF0.382C R/W CAM4 Least Significant Word Register 0x0000.0000
