EMC 1 Status Registers
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
MAC REGISTERS
MISTA_1 0xFFF0.38B4 R/W MAC Interrupt Status Register 0x0000.0000
MGSTA_1 0xFFF0.38B8 R/W MAC General Status Register 0x0000.0000
MRPC_1 0xFFF0.38BC R MAC Receive Pause count register 0x0000.0000
MRPCC_1 0xFFF0.38C0 R MAC Receive Pause Current Count Register 0x0000.0000
MREPC_1 0xFFF0.38C4 R MAC Remote pause count register 0x0000.0000
DMA REGISTERS
DMARFS_1 0xFFF0.38C8 R/W DMA Receive Frame Status Register 0x0000.0000
CTXDSA_1 0xFFF0.38CC R
Current Transmit Descriptor Start Address
Register
0x0000.0000
CTXBSA_1 0xFFF0.38D0 R Current Transmit Buffer Start Address Register 0x0000.0000
CRXDSA_1 0xFFF0.38D4 R
Current Receive Descriptor Start Address
Register
0x0000.0000
CRXBSA_1 0xFFF0.38D8 R Current Receive Buffer Start Address Register 0x0000.0000
GDMA Registers Map
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
GDMA_CTL0 0xFFF0.4000 R/W Channel 0 Control Register 0x0000.0000
GDMA_SRCB0 0xFFF0.4004 R/W Channel 0 Source Base Address Register 0x0000.0000
GDMA_DSTB0 0xFFF0.4008 R/W Channel 0 Destination Base Address Register 0x0000.0000
GDMA_TCNT0 0xFFF0.400C R/W Channel 0 Transfer Count Register 0x0000.0000
GDMA_CSRC0 0xFFF0.4010 R Channel 0 Current Source Address Register 0x0000.0000
GDMA_CDST0 0xFFF0.4014 R Channel 0 Current Destination Address Register 0x0000.0000
GDMA_CTCNT0 0xFFF0.4018 R Channel 0 Current Transfer Count Register 0x0000.0000
GDMA_CTL1 0xFFF0.4020 R/W Channel 1 Control Register 0x0000.0000
GDMA_SRCB1 0xFFF0.4024 R/W Channel 1 Source Base Address Register 0x0000.0000
GDMA_DSTB1 0xFFF0.4028 R/W Channel 1 Destination Base Address Register 0x0000.0000
GDMA_TCNT1 0xFFF0.402C R/W Channel 1 Transfer Count Register 0x0000.0000
GDMA_CSRC1 0xFFF0.4030 R Channel 1 Current Source Address Register 0x0000.0000
GDMA_CDST1 0xFFF0.4034 R Channel 1 Current Destination Address Register 0x0000.0000
GDMA_CTCNT1 0xFFF0.4038 R Channel 1 Current Transfer Count Register 0x0000.0000
