W90N740

- 36 -

7.3.2.1 SDRAM Components Supported
• 16M bit SDRAM

− 2Mx8 with 2 banks ;RA0 ~ RA10, CA0 ~ CA8

− 1Mx16 with 2 banks;RA0 ~ RA10, CA0 ~ CA7

• 64M bit SDRAM

− 8Mx8 with 4 banks;RA0 ~ RA11, CA0 ~ CA8

− 4Mx16 with 4 banks;RA0 ~ RA11, CA0 ~ CA7

− 2Mx32 with 4 banks ;RA0 ~ RA10, CA0 ~ CA7

• 128M bit SDRAM

− 16Mx8 with 4 banks;RA0 ~ RA11, CA0 ~ CA9

− 8Mx16 with 4 banks;RA0 ~ RA11, CA0 ~ CA8

− 4Mx32 with 4 banks;RA0 ~ RA11, CA0 ~ CA7

• 256M bit SDRAM

− 32Mx8 with 4 banks;RA0 ~ RA12, CA0 ~ CA9

− 16Mx16 with 4 banks;RA0 ~ RA12, CA0 ~ CA8

7.3.2.2 AHB Bus Address Mapping to SDRAM Bus

Note: * indicates the signal is not used; ** indicates the signal is fixed at logic 0 and is not used;

The HADDR prefixes have been omitted on the following tables.

A14 ~ A0 are the Address pins of the W90N740 EBI interface;

A14 and A13 are the Bank Selected Signal of SDRAM.
