W90N740
- 146 -
Host Controller Bulk Current ED Register (HcBulkCurrentED)
Register Address R/W Description Reset Value
HcBulkCurrentED 0xFFF0.502C R/W Host Controller Bulk Current ED Register 0x0000.0000
Register: HcBulkCurrentED
Bits Reset R/W Description
3-0 0h - Reserved. Read/Write 0's
31-4 0h R/W
BulkCurrentED
Pointer to the current Bulk List ED.
Host Controller Done Head Register (HcDoneHead)
Register Address R/W Description Reset Value
HcDoneHead 0xFFF0.5030 R/W Host Controller Done Head Register 0x0000.0000
Register: HcDoneHead
Bits Reset R/W Description
3-0 0h - Reserved. Read/Write 0's
31-4 0h R/W
DoneHead
Pointer to the current Done List Head ED.
Host Controller Frame Interval Register (HcFmInterval)
Register Address R/W Description Reset Value
HcFmInterval 0xFFF0.5034 R/W Host Controller Frame Interval Register 0x0000.2EDF
Register: HcFmInterval
Bits Reset R/W Description
13-0 2EDFh R/W
FrameInterval
This field specifies the length of a frame as (bit times - 1). For 12,000 bit
times in a frame, a value of 11,999 is stored here.
15-14 0h - Reserved. Read/Write 0's
