W90N740
- 152 -
Host Controller Root Hub Port Status (HcRhPortStatus [1:2])
This register is reset by the U
SB
R
ESET
state.
Register Address R/W Description Reset Value
HcRhPortStatus [1] 0xFFF0.5054 R/W Host Controller Root Hub Port Status [1] 0x0000.0000
HcRhPortStatus [2] 0xFFF0.5058 R/W Host Controller Root Hub Port Status [2] 0x0000.0000
Register: HcRhPortStatus[1:2]
Bits Reset R/W Description
0 0 R/W
(Read) CurrentConnectStatus
0 = No device connected.
1 = Device connected.
NOTE: If DeviceRemoveable is set (not removable) this bit is always '1'.
(Write) ClearPortEnable
Writing '1' a clears PortEnableStatus. Writing a '0' has no effect.
1 0 R/W
(Read) PortEnableStatus
0 = Port disabled.
1 = Port enabled.
(Write) SetPortEnable
Writing a '1' sets PortEnableStatus. Writing a '0' has no effect.
2 0 R/W
(Read) PortSuspendStatus
0 = Port is not suspended
1 = Port is selectively suspended
(Write) SetPortSuspend
Writing a '1' sets PortSuspendStatus. Writing a '0' has no effect.
3 0 R/W
(Read) PortOverCurrentIndicator
HYDRA-2 supports global over-current reporting. This bit reflects the
state of the OVRCUR pin dedicated to this port. This field is only valid if
NoOverCurrentProtection is cleared and OverCurrentProtectionMode
is set.
0 = No over-current condition
1 = Over-current condition
(Write) ClearPortSuspend
Writing a '1' initiates the selective resume sequence for the port. Writing
a '0' has no effect.
4 0 R/W
(Read) PortResetStatus
0 = Port reset signal is not active.
1 = Port reset signal is active.
(Write) SetPortReset
Writing a '1' sets PortResetStatus. Writing a '0' has no effect.
