W90N740
Publication Release Date: November 26, 2004
- 211 - Revision A4
NATA Registers Map
REGISTER OFFSET R/W DESCRIPTION RESET VALUE
NATA Control and Status Registers
NATCMD 0xFFF0.6000 R/W NAT Command Register 0x0000.0000
NATCCLR0 0xFFF0.6010 W NAT Counter 0 Clear Register 0x0000.0000
NATCCLR1 0xFFF0.6014 W NAT Counter 1 Clear Register 0x0000.0000
NATCCLR2 0xFFF0.6018 W NAT Counter 2 Clear Register 0x0000.0000
NATCCLR3 0xFFF0.601C W NAT Counter 3 Clear Register 0x0000.0000
NATCFG0 0xFFF0.6100 R/W NAT Entry 0 Configuration Register 0x0000.0000
NATCFG1 0xFFF0.6104 R/W NAT Entry 1 Configuration Register 0x0000.0000
.
.
. .
.
. .
.
. .
.
. .
.
.
NATCFG63 0xFFF0.61FC R/W NAT Entry 63 Configuration Register 0x0000.0000
EXMACM 0xFFF0.6200 R/W
External MAC Address Most Significant Word
Register
0x0000.0000
EXMACL 0xFFF0.6204 R/W
External MAC Address Least Significant Word
Register
0x0000.0000
INMACM 0xFFF0.6208 R/W
Internal MAC Address Most Significant Word
Register
0x0000.0000
INMACL 0xFFF0.620C R/W
Internal MAC Address Least Significant Word
Register
0x0000.0000
