W90N740
- 120 -
NATCCLR2
31 30 29 28 27 26 25 24
CLREH47 CLREH46 CLREH45 CLREH44 CLREH43 CLREH42 CLREH41 CLREH40
23 22 21 20 19 18 17 16
CLREH39 CLREH38 CLREH37 CLREH36 CLREH35 CLREH34 CLREH33 CLREH32
15 14 13 12 11 10 9 8
CLRCNT47 CLRCNT46 CLRCNT45 CLRCNT44 CLRCNT43 CLRCNT42 CLRCNT41 CLRCNT40
7 6 5 4 3 2 1 0
CLRCNT39 CLRCNT38 CLRCNT37 CLRCNT36 CLRCNT35 CLRCNT34 CLRCNT33 CLRCNT32
7.6.2.3 NATCCLR3
31 30 29 28 27 26 25 24
CLREH63 CLREH62 CLREH61 CLREH60 CLREH59 CLREH58 CLREH57 CLREH56
23 22 21 20 19 18 17 16
CLREH55 CLREH54 CLREH53 CLREH52 CLREH51 CLREH50 CLREH49 CLREH48
15 14 13 12 11 10 9 8
CLRCNT63 CLRCNT62 CLRCNT61 CLRCNT60 CLRCNT59 CLRCNT58 CLRCNT57 CLRCNT56
7 6 5 4 3 2 1 0
CLRCNT55 CLRCNT54 CLRCNT53 CLRCNT52 CLRCNT51 CLRCNT50 CLRCNT49 CLRCNT48
CLREHx (x: 63 ~ 0) [31:16]: Entry x hit counter clear bit
Default value: 0
Set the appropriate bit to clear the corresponding entry x hit counter (EHCNTx); writing zero to the bit
has no effect. About the usage of EHCNTx, please see details in NATCFGx.
CLRCNTx (x: 63 ~ 0) [15:0]: NATA Entry x counter clear bit
Default value: 0
Set the appropriate bit to clear the corresponding entry counter (CNTx); writing zero to the bit has no
effect. About the usage of CNTx, please see details in NATCFGx.
