W90N740
Publication Release Date: November 26, 2004
- 123 - Revision A4
ExEN [0]: Entry x Comparison Enable bit
Default value: 0
Set the bits to selectively enable entry location comparison. To disable an entry location, clear the
appropriate bit. If S/W wants to change some entry data, it has to disable the selected entry and
monitor corresponding CNTx till the value is 0, then it is acceptable to change new entry data.
NAT Entry Configuration Register (NATCFGx) Application Note:
MA: masquerading IP address
MP: masquerading port number
LA: local mapping IP address
LP: local mapping port number
SA: (IP) address at source field
SP: port number at source field
DA: (IP) address at destination field
DP: port number at destination field
Data Content in the NATA table
Field 0 Field 1 Field 2 Field 3
Entry 0 MA 0 MP 0 LA 0 LP 0
Entry 1 MA 0 MP 0 LA 0 LP 0
…. …. …. …. ….
Entry 15 MA 15 MP 15 LA 15 LP 15
