W90N740
- 74 -
These registers are used for loading commands generated by user, indicating transmit and receive
status, buffering data to/from memory, and providing interrupt control. The registers used by
W90N740 EMC (Ethernet MAC controller) are divided into three groups:
• CAM REGISTERS
• MAC REGISTERS
• DMA REGISTERS
Note: registers are named as xxxx_0 or xxxx_1, where xxxx_0 is the register in EMC 0, and xxxx_1 is
the register in EMC 1.
EMC 0 Control registers
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
CAM REGISTERS
CAMCMR_0 0xFFF0.3000 R/W CAM Command Register 0x0000.0000
CAMEN_0 0xFFF0.3004 R/W CAM enable register 0x0000.0000
CAM0M_0 0xFFF0.3008 R/W CAM0 Most Significant Word Register 0x0000.0000
CAM0L_0 0xFFF0.300C R/W CAM0 Least Significant Word Register 0x0000.0000
CAM1M_0 0xFFF0.3010 R/W CAM1 Most Significant Word Register 0x0000.0000
CAM1L_0 0xFFF0.3014 R/W CAM1 Least Significant Word Register 0x0000.0000
CAM2M_0 0xFFF0.3018 R/W CAM2 Most Significant Word Register 0x0000.0000
CAM2L_0 0xFFF0.301C R/W CAM2 Least Significant Word Register 0x0000.0000
CAM3M_0 0xFFF0.3020 R/W CAM3 Most Significant Word Register 0x0000.0000
CAM3L_0 0xFFF0.3024 R/W CAM3 Least Significant Word Register 0x0000.0000
CAM4M_0 0xFFF0.3028 R/W CAM4 Most Significant Word Register 0x0000.0000
CAM4L_0 0xFFF0.302C R/W CAM4 Least Significant Word Register 0x0000.0000
CAM5M_0 0xFFF0.3030 R/W CAM5 Most Significant Word Register 0x0000.0000
CAM5L_0 0xFFF0.3034 R/W CAM5 Least Significant Word Register 0x0000.0000
CAM6M_0 0xFFF0.3038 R/W CAM6 Most Significant Word Register 0x0000.0000
CAM6L_0 0xFFF0.303C R/W CAM6 Least Significant Word Register 0x0000.0000
CAM7M_0 0xFFF0.3040 R/W CAM7 Most Significant Word Register 0x0000.0000
CAM7L_0 0xFFF0.3044 R/W CAM7 Least Significant Word Register 0x0000.0000
CAM8M_0 0xFFF0.3048 R/W CAM8 Most Significant Word Register 0x0000.0000
CAM8L_0 0xFFF0.304C R/W CAM8 Least Significant Word Register 0x0000.0000
CAM9M_0 0xFFF0.3050 R/W CAM9 Most Significant Word Register 0x0000.0000
