Turbo iDDR User Guide 259
Remote control operation: In Workstation mode
Guide to AMP Player: Protocol Only mode
The Protocol control only mode allows you to only monitor play channel operations
and view clip information. All control comes from the external device. The buttons,
menu items, and other interface controls are disabled. You can select this mode by
choosing the
Protocol control only option in the Options dialog box. ( See “Select the
control port and control mode” on page 255 .)
Channel status information displayed includes current clip timecode, current clip
name, countdown to the preview clip, and preview clip name.
The following describes the indicators displayed Protocol control only mode.
Control Description and User Operation
"
Assignable Buttons Assignable buttons allow you to modify the button assignment to
best suit your workflow. Holding down a button longer than one
second opens the button pop-up menu which lists the alternative
button choices.
Button choices include Options or Properties. The buttons function
the same as the context menu items.
# Current Timecode Indicates the current timecode of the timecode of the clip. The
timecode value of XX:XX:XX:XX is displayed when there is no
recorded timecode.
See “Striping timecode (replacing the timecode
track)” on page 157 .
$ EE or Playback Selection The text displayed to the right of clip timecode indicates the playback
mode selection: EE or PB. When E to E is selected, the play channel
output switches to the record channel input when playback is
stopped. When PB is selected, play channel output freezes on the last
video frame. To select the playback mode, refer
“Selecting E-to-E
mode” on page 150 .
Clip
Timecode PB or EE
Mode
(Indicates the
selected mode) 2 3 4 Clip Name &
Current Bin
6
Assignable
Buttons
(Default buttons
are shown) 1
Time Dome Thumbnail
(Current and
Preview clips) 7
5 Countdown
Timecode
