EXFO FTB/IQS-88000 Series Power Blazer for FTB-2/2Pro/500/IQS-600 User Manual
Page 86
Test Setup - Test Configurator, Timer, and System
74
FTB/IQS-88000 Series
Test Configurator Overview
Fibre Channel Test Application:
Test Application indicates the selected test application.
Topology, for Transport Test Applications, indicates the selected test
topology.
Modify Structure button, allows the configuration of the physical port
and the signal interface structure.
Modify Structure
Protocol Block
Test Block
Clock Block
Interface Block
Physical
Interface Port
Test Application
Arrows
