Physical Interfaces and LEDs
18 FTB/IQS-88000 Series
SFP/SFP+ (PORT #1/#2)
SFP/SFP+ (PORT #1/#2)
SFP/SFP+ ports can be used for the following test applications and rates:
Plug the SFP/SFP+ module into the SFP/SFP+ PORT #1 or PORT #2 slot
on the module.
Note: Use only EXFO supported transceivers. Refer to the Specifications on
page 537 for the list of supported transceivers. Using non-supported
transceivers can affect the performance and accuracy of the test.
Note: Do not replace a SFP/SFP+ while the test is running to avoid distorting
statistics. First stop the test case, replace the SFP/SFP+ and then restart the
test.
Application Rates
PORT
#1 #2
Transport OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,
OTU1, OC-192/STM-64, OTU2, OTU1e, OTU2e, OTU1f,
OTU2f X
Ethernet 100Mbit/s, 1000 Mbit/s, 10Gbit/s X X
Packet Sync 100Mbit/s, 1000 Mbit/s, 10Gbit/s X X
Fibre Channel 1X, 2X, 4X, 8X, 10X X X
16X X
