Lpbk Tool Button (Loopback Tool)
Interface Tab
Physical Interface
Interface/Rate allows the selection of the loopback tool interface
rate: 10/100/1000M Electrical (default), 100M Optical,
1GE Optical, or 10GE LAN. 10GE LAN is only available when the
loopback tool runs on Port #1.
Connector displays the module’s port for the selected
interface/rate.
Clock Mode: Displays the clock mode
Internal: Internal clock of the unit (STRATUM 3).
RX Power (dBm) indicates the current received power level of the
optical laser in dBm.
Green: Power level in range.
Yellow: Power level out-of-range.
Red: Loss of signal or power level is close to damage.
Gray: Invalid operational range value or not supported by the
optical transceiver.
Power Range (dBm) indicates, when supported, the received
power level range of the optical laser in dBm.
Interface/Rate
Connector
10GE LAN
Port 1 - XFP
Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
1GE Optical
100M Optical
Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
10/100/1000M Electrical
Port 1 - RJ45
