Test Results
366
FTB/IQS-88000 Series
Summary (1588 PTP)
Negotiation Status
The status of the PTP Negotiation is displayed while in Unicast
negotiation.
Negotiation
Status
Description
Background
Color
a
a.
The gray background color is also used for a Link Down.
Request Granted
All the Signaling request types have been granted.
Green
[Message type]
Request Denied
The Signaling grant message has not been granted.
Red
Session Canceled
The Grand Master has canceled the Unicast session.
Red
No Reply
No message is received from the Grand Master following
transmission of 3 Signaling requests for a message type.
Make sure that both IP address and Domain (refer to 1588 PTP on
page 97) of the Grand Master Clock are valid as well as the IP
address of the unit’s port used to connect on the network (refer to
Network on page 162).
Red
Pending
Unicast negotiation has started and no message has been received
from the Grand Master.
Gray
Inactive
The Unicast negotiation is not active.
Gray
