For fibre channel test application – EXFO FTB/IQS-88000 Series Power Blazer for FTB-2/2Pro/500/IQS-600 User Manual
Page 107
Test Setup - Test Configurator, Timer, and System
Power Blazer
95
Modify Structure Button
For Fibre Channel Test Application
Interface/Rate: Select the desired interface rate. Choices depend on
the rates available on the module.
Connector: Allows the selection of the module’s port available for the
selected interface/rate.
Interface/Rate
Module
1X
2X
4X
8X
10X
88100NGE
8830NGE
8830NGE-16X
16X
8830NGE-16X
Interface/Rate
Connector
1X
2X
4X
8X
Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
10X
Port 1 - XFP
Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
16X
Port 2 - SFP/SFP+
