Specifications
548 FTB/IQS-88000 Series
XFP SONET/SDH and OTN Optical Interface
XFP SONET/SDH and OTN Optical Interface
Electrical Ethernet Interfaces
Transceiver type OC-192/STM-64/OTU2 OC-192/STM-64/OTU2 OC-192/STM-64/OTU2
Wavelength (nm) 1310 1550 1550
Model FTB-81900 FTB-81901 FTB-81902
Tx level (dBm) –6.0 to –1.0 –1.0 to 2.0 0 to 4.0
Rx level (dBm) –13.4 to 0.5 –15.0 to –1.0 –22.5 to –7.0
Maximum reach 10 km 40 km 80 km
Tx bit rate (Gbit/s)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
Frequency offset generation (ppm) ±50 ±50 ±50
Rx bit rate (Gbit/s)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
9.953 (OC-192/STM-64)
10.709 (OTU2)
11.049 (OTU1e)
11.095 (OTU2e)
11.27 (OTU1f)
11.31 (OTU2f)
Tx wavelength range (nm) 1290 to 1330 1530 to 1565 1530 to 1565
Rx wavelength range (nm) 1270 to 1600 1270 to 1600 1270 to 1600
Measurement accuracy (ppm) ±4.6 ±4.6 ±4.6
Rx damage level max. (dBm) 5 6 5
Jitter compliance
GR-253 (SONET)
G.825 (SDH)
G.8251 (OTN)
GR-253 (SONET)
G.825 (SDH)
G.8251 (OTN)
GR-253 (SONET)
G.825 (SDH)
G.8251 (OTN)
Laser type DFB EML EML
Laser product Class 1 Class 1 Class 1
Connector LC LC LC
10/100 BASE-T half/full duplex, 1000 BASE-T full duplex
Automatic or manual detection of straight/crossover cable
Transceiver type 10 BASE-T 100 BASE-TX 1000 BASE-T
Tx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Tx accuracy (uncertainty) (ppm) ±4.6 ±4.6 ±4.6
Rx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Rx measurement accuracy (uncertainty) (ppm) ±4.6 ±4.6
Duplex mode Half and full duplex Half and full duplex Full duplex
Jitter compliance IEEE 802.3 IEEE 802.3 IEEE 802.3
Connector RJ-45 RJ-45 RJ-45
Maximum reach (m) 100 100 100
