Test Setup - Test Configurator, Timer, and System
90 FTB/IQS-88000 Series
Modify Structure Button

Connector is the module’s port available for the selected
interface/rate.

CFP: Use this configuration when an optical transceiver is inserted
in the CFP INTERFACE slot of the FTB-800v2 Series module.

CFP2: Use this configuration when an EXFO CFP to CFP2 adapter is
inserted in the CFP slot of the FTB-800v2 Series module.

Internal Loopback: Use this configuration to perform a loopback
before the CFP connector of each physical lane without interfacing
with the optical transceiver.
Note: The Internal Loopback connector selection allows the isolation of the
FTB-1v2 Pro module CFP slot electrical interface from the CFP device. This
can be useful in isolating a problem to a faulty CFP device.
Interface/Rate Connector
100GE (10 Lanes) [103.125Gbit/s]
100GE (4 Lanes) [103.125 Gbit/s]
40GE (4 Lanes) [41.25 Gbit/s] Port 2 - CFP
Port 2 - CFP2 (100GE only)
Port 2 - Internal Loopback
10GE WAN
10GE LAN Port 1 - XFP
Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
1GE Optical
100M Optical Port 1 - SFP/SFP+
Port 2 - SFP/SFP+
10/100/1000M Electrical Port 1 - RJ45
FTB-800v2 Series
Testing Unit
Internal Loopback
