Physical Interfaces and LEDs
This section describes all connectors (ports) and LEDs available on the
FTB/IQS-88000 Series module.
FTB-88100NGE/88100G/8830NGE/8830NGE-16X
Note: The FTB-88100NGE is shown below as an example for connector location
purposes.
C
AUTION
To prevent exceeding the maximum input/output power level,
please refer to the Specifications on page 537.
External Clock
CFP
1
Port #2
Reference Output
SFP/SFP+
1
Port #2
XFP
1
Port #1
SFP/SFP+
1
Port #1
RJ45 Port #1
1. Laser radiation emitted from this port when LASER LED is on.
