Specifications
Power Blazer 545
SFP+ Fibre Channel Optical Interfaces
SFP+ Fibre Channel Optical Interfaces
FC-8x/10x
Wavelength (nm) 850 850 1310 1550 1550
Model FTB-8696 FTB-8690 FTB-8693 FTB-8694 FTB-8695
Tx level (dBm) –8.2 to –2 –5 to –1 –6 to –1 –1 to 2 0 to 4
Rx level sensitivity (dBm) –11.1 to 0 –11.1 to 0.5 –14.4 to 0.5 –14 to –1 –24 to –7
Maximum reach 150 m on OM3 MMF 300 m on OM3 MMF 10 km 40 km 80 km
Transmission bit rate (Gbit/s) 8.5 10.5 8.5/10.5 8.5/10.5 8.5/10.5
Reception bit rate (Gbit/s) 8.5 10.5 8.5/10.5 8.5/10.5 8.5/10.5
Tx operational wavelength range (nm) 840 to 860 840 to 860 1260 to 1355 1530 to 1565 1530 to 1565
Measurement accuracy (uncertainty)
Frequency (ppm)
Optical power (dB)
±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
Max Rx before damage (dBm) 5 5 5 5 3
Jitter compliance ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3
FC classification ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3
Laser type VCSEL VCSEL DFB CML EML
Eye safety Class 1 Class 1 Class 1 Class 1 Class 1
Connector LC LC LC LC LC
