Specifications
Power Blazer 539
100G Pluggable Transceivers (CFP2)
100G Pluggable Transceivers (CFP2)
The TX operational wavelength (nm) range per Lane is as follows.
100GBASE-SR10 100GBASE-LR4
Lane 0
Lane 1
Lane 2
Lane 3
Lane 4
Lane 5
Lane 6
Lane 7
Lane 8
Lane 9
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
840 to 860
1294.53 to 1296.59
1299.02 to 1301.09
1303.54 to 1305.63
1308.09 to 1310.19
( )
CFP2-85974 CFP2-85975 CFP2-85978
100GBASE-SR10 single-rate
(100GE) CFP2
100GBASE-LR4 dual-rate
(100GE/OTU4) CFP2
100GBASE-LR4/OTU4
dual-rate
Manufacturer part number AVAGO AFBR-8420Z NEOPHOTONICS PT-C24C3LDCL FINISAR FTLC1121SDNL
Compliance
CFP2 MSA CAUI/CPPI
100GBASE-SR10 IEEE 802.3ba
CFP2 MSA CAUI-4
100GBASE-LR4 IEEE 802.3ba OTN OTU4
4I1-9D1F ITU-T G.959
CFP2 MSA CAUI-4
100GBASE-LR4 IEEE 802.3ba OTN OTU4
4I1-9D1F ITU-T G.959
Average Tx power per lane (dBm) —7.6 to —1 —2.5 to 2.9 —4.3 to 4.5/—0.6 to 4.0
Average Rx level per lane (dBm) —9.5 to 2.4 Up to 2.9 —10.6 to 4.5/—6.9 to 4.0
Max. reach
100 m/OM3
150 m/OM4
10 km 10 km
Transmission bit rate,
per optical lane (Gbit/s)
10.3125 10.3125/11.181 10.3125/11.181
Reception bit rate per
optical lane (Gbit/s)
10.3125 10.3125/11.181 10.3125/11.181
Operational wavelength range (nm) 840 to 860 1294.53 to 1310.19 1294.53 to 1310.19
Operational wavelengths
Refer to the
FTB/IQS-88100G
User Guide for full list.
Refer to the
FTB/IQS-88100G
User Guide for full list.
Refer to the
FTB/IQS-85100G Series
User Guide for full list.
Measurement accuracy (uncertainty)
Frequency (ppm)
Optical power (dB)
±4.6
±2
±4.6
±2
±4.6
±2
Max. Rx before damage,
per lane (dBm)
3.4 5.5 5.5
Jitter compliance Per 802.3ba Per 802.3ba and G.8251 Per 802.3ba and G.8251
Laser product Class 1 Class 1 Class 1
Connector MPO-24 LC LC
Transceiver type CFP2 CFP2 CFP2
