Test Setup - Test Configurator, Timer, and System
182 FTB/IQS-88000 Series
S-OAM and MPLS-TP OAM
Next HOP Router (G.8113.1)

MAC Address, available when Resolve MAC check box is cleared,
allows to enter the Next HOP Router MAC address: 00:00:00:00:00:00 to
FF:FF:FF:FF:FF:FF, default is 01:00:5E:90:00:00
1
. The MAC Address field
is not accessible when the Resolve MAC check box is selected.

Resolve MAC check box, when selected (cleared by default), sends a
request to the network to retrieve the MAC address corresponding to
the selected IP address.

IP Address, available when Resolve MAC check box is selected,
allows to enter the Next HOP Router IP address: 0.0.0.0 to
255.255.255.255 for IPv4; default is the source IP address; ::1 to
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for IPv6, default is 2001::.
Local Parameters

MEG ID (Y.1731 and G.8113.1) is the Maintenance Entity Group Level
identification allowing to enter a 13-bytes MEG ID value/message to be
generated (default value is EXFO MEG ID). Values should be ASCII
suitable characters including the ITU T.50 Characters on page 31.
Padding allows the selection of the character (Null or Space) to used
for remaining byte values.

MAID (802.1ag and MEF) is a 45 bytes Maintenance Association
Identification that is divided into two parameters:

Domain ID is an optional domain identification text field
(0 byte (Domain ID not present), up to 44 bytes minus the
MA Name field length) set to EXFO Domain ID by default.

MA Name (Short MA Name) is a Maintenance Association Name
text field set to EXFO MA Name by default. The length of the MA
Name field is from 1 to either 44 bytes minus the Domain ID field
length when Domain ID is present or 45 bytes when not present.
1. The MAC Address 01:00:5E:90:00:00 is reserved for point-to-point link and can be used when the unicast address is
unknown (as per RFC-7213).
