Test Results
Power Blazer 405
Traffic - S-OAM and MPLS-TP OAM
Responder
Note: Available when the S-OAM Responder or MPLS-TP OAM Responder check
box is selected (refer to S-OAM and MPLS-TP OAM Responder on
page 180).
For Carrier Ethernet OAM test application:

In TX, reports counts of LBR, LTR
1
, DMR, LMR, and SLR
1
total frames
transmitted.

In RX, reports counts of valid LBM, LTM
1
, DMM, LMM, and SLM
1
unicast, multicast, and total frames received. A valid messages must
have its:
S-OAM: source MAC address matching the Peer MEP MAC address;
destination MAC address matching either the unit port Unicast MAC
address or a Multicast class 1 or class 2 address
2
; VLANs matching the
unit port VLANs, and MEG/MD Level matching the local MEG/MD Level.
MPLS-TP OAM: destination MAC address matching either the unit MAC
address, FF:FF:FF:FF:FF:FF, or 01:00:5E:90:00:00; VLANs matching the
unit port VLANs; and MPL Labels matching the local MPLS Label Stack
configuration.
For Smart Loopback test application:

In TX, reports counts of LBR, LTR, DMR, LMR, and SLR total frames
transmitted.

In RX, reports counts of valid LBM, LTM, DMM, LMM, and SLM total
frames received. A valid messages must have its destination MAC
address matching either the unit port Unicast MAC address or a
Multicast class 1 or class 2 address
2
.
1. Only available with Ethernet OAM.
2. Refer to Unicast/Multicast Addresses for Ethernet OAM on page 623 for more information.
