Test Results
404 FTB/IQS-88000 Series
Traffic - S-OAM and MPLS-TP OAM
Traffic - S-OAM and MPLS-TP OAM
From the Test menu, tap Results, Traffic, and the S-OAM or MPLS-TP OAM
tab.
Traffic Monitoring
Note: Only available with Carrier Ethernet OAM test application.

In TX, reports counts of CCM, LBM, LTM
1
, DMM, LMM, SLM
1
, TST, AIS,
LCK, and CSF frames transmitted. Total count is reported as well as
unicast and/or multicast frame counts when applicable.

In RX, reports counts of CCM, LBR, LTR
1
, DMR, LMR, SLR
1
, TST AIS,
LCK, and CSF frames received regardless of the sender as long as the
following criteria are met:

S-OAM: The destination MAC address matches either the local MEP
Unicast MAC address or a Multicast class 1 or class 2 address
2
; and
the VLANs matches the unit port VLANs.

MPLS-TP OAM: The destination MAC address matches either the
unit MAC address, FF:FF:FF:FF:FF:FF, or 01:00:5E:90:00:00; the
VLANs matches the unit port VLANs; and MPL Labels matches the
local MPLS Label Stack configuration. For AIS, LCK, and CSF, valid
messages must also have the MEG Level matching the Local MEG
Level.
Total count is reported as well as unicast and/or multicast frame counts
when applicable.
1. Only available with Ethernet OAM.
2. Refer to Unicast/Multicast Addresses for Ethernet OAM on page 623 for more information.
